WEIGHTS AND MEASURES
DIMENSIONS
Overall Length (approx.) 39' 4"
Wheel Base 279"
Overall Width 101"
Overall Height 13' 3"
Minimum Garage Height 14'
Interior Height 82.5"
Interior Width 96"
Square Footage (approx.) 310
Basement Storage (cubic feet, approx.) 136
WEIGHT LIMITS
GAWR-Front (pounds) 12000
GAWR-Rear (pounds) 21000
GVWR (pounds) 33000
Maximum Trailer Weight (pounds) 12000
Hitch Rating (pounds) 12000
GCWR (pounds) 45000
CAPACITIES
Fuel Tank (gallons) 100
DEF Tank (gallons) 10
Fresh Water (gallons) 150
Grey Water (gallons) 70
Black Water (gallons) 45
QUANTITIES
Number of Slideouts 3
Sleeping Capacity 6 to 8
Seat Belts 8
Seating Capacity 6 to 8
CHASSIS AND DRIVETRAIN FEATURES
Freightliner® S2RV Chassis STD
Cummins® B6.7 360 HP Diesel Engine with 800 lb-ft Torque 10 STD
Two-wheel Drive STD
185-Amp Alternator STD
Allison® 3000 MH 6-speed Automatic Transmission with Lock-up Torque Converter STD
Front and Rear 275/80R 22.5 Tires STD
Hydraulic Leveling Jacks with Control Panel STD
Taper Leaf Front Suspension STD
Freightliner® Airliner® Rear Suspension with Manual Dump Valve STD
Rear Sway Bar STD
Custom Tuned Sachs® Shock Absorbers STD
Eaton Tractech NoSPIN® Differential STD
Front Radiator STD
Full Air Brake System with Automatic Slack Adjusters STD
Heated Air Tanks with Auto Drain Valve STD
Single Stage Variable Geometry Turbocharger (VGT) Engine Brake STD
Manual Parking Brake STD
Rear Fuel Fill STD
Automatic Traction Control STD
Cruise Control STD
Tire Inflation Kit with Quick Disconnect Fitting STD
Black Aluminum Wheels 11 OPT
